Hacking the Inference Pareto Frontier - Kyle Kranen, NVIDIA


Chapters

0:0 Introduction to Breaking the Inference Pareto Frontier
0:33 Introduction of Kyle Cranon and NVIDIA Dynamo
1:31 The Three Pillars of Deployment (Quality, Latency, Cost)
2:11 Understanding the Pareto Frontier
3:6 Application-Specific Prioritization of Quality, Latency, and Cost
4:32 Common Techniques to Manipulate the Pareto Frontier (Quantization, RAG, Reasoning)
5:19 Compounding Techniques
6:4 Three Drivers for Modifying the Pareto Frontier (Scale, Structure, Dynamism)
6:20 Scale: Disaggregation
11:2 Scale: Routing
13:0 Structure: Inference Time Scaling
16:14 Structure: KV Manipulation
17:43 Dynamism: Worker Specialization
18:42 Dynamism: Dynamic Load Balancing
19:55 Conclusion and NVIDIA Dynamo Resources

Whisper Transcript | Transcript Only Page

00:00:00.040 | Hey there, everyone. I'm Kyle Cranin and today I'll be talking about how to break the inference
00:00:18.760 | Pareto frontier in your advantage. Really, the thing that enables the success is that a good
00:00:25.240 | model and a good system that takes into account the actual constraints for what you need from
00:00:30.460 | your deployment is actually key to the success of both your deployment and the application
00:00:35.260 | that is backed by it. So, who am I and why am I talking about this? As I said, my name
00:00:42.120 | is Kyle Cranin. Currently, I work at NVIDIA. Previously at NVIDIA, I was leading and GMing
00:00:50.680 | the largest inference deployment at NVIDIA with a multiple tens of millions dollar quarterly
00:00:56.080 | cloud bill. And now I'm an architect and lead for a project that we just released an open
00:01:01.420 | source called NVIDIA Dynamo that aims to do things like enable data center scale inference
00:01:07.300 | to manipulate your deployment and manipulate the Pareto frontier in order to achieve better
00:01:12.020 | SLAs or achieve lower costs for existing SLAs with techniques like disaggregation or more
00:01:17.880 | techniques that we'll talk about later in the talk. Dynamo is... The Dynamo meetup is linked
00:01:23.600 | right here. You can learn more about Dynamo there if you want to look it up. And I'll also have
00:01:27.240 | that at the end of the talk as well. So, the three things that we or I like to think about
00:01:33.620 | when I'm thinking about whether or not something can actually be deployed and used is really simple.
00:01:39.020 | It's quality. Whether or not your application and the system around your model is capable of, you know,
00:01:44.420 | completing tasks with some level of accuracy or quality. Latency. Whether or not the task can be
00:01:50.720 | completed in a fast enough envelope for, you know, either the user to be happy or to meet safety
00:01:55.520 | guarantees like for robotics. And cost. Can the LLM complete the task cheaply enough per request in
00:02:03.200 | order for you to meet whatever, you know, margin requirements you have for your application.
00:02:07.160 | And one of the ways that we generally compare these three things is through Pareto frontier. Now,
00:02:14.720 | the frontier I'm showing here is two-dimensional. It's actually really hard to plot things in 3D on
00:02:19.700 | a 2D slide. So, I'm gonna just show two dimensions. Really what this looks like is you have this, like,
00:02:24.600 | edge. We have this edge that sort of represents the best or to the top and rightmost points that we
00:02:35.700 | achieve for, you know, a specific set of attributes. So, in this case, we have the TPS per GPU, which is
00:02:42.700 | effectively a cost metric. How many requests can you handle per GPU per second? And the user TPS,
00:02:48.000 | which is a responsiveness metric, right? So, this is the latency versus the cost. And for different
00:02:53.340 | applications, really, you want to enable your Pareto front -- enable -- you actually really only want one
00:03:00.540 | point on the Pareto frontier. It's right. What is your operating latency? What is the operating quality
00:03:04.440 | you need? And how can you minimize cost for that? Now, this really actually depends on the application
00:03:09.960 | you're talking about. So, one of the most important things you're doing when you're thinking about breaking
00:03:14.460 | the Pareto frontier is you're thinking about your application. So, for example, if we're talking
00:03:18.840 | about personal cancer cures, which is a topic that's talked about a lot in the context of generative AI,
00:03:24.060 | in that situation, latency and cost are pretty much no object, right? You could spend millions of dollars
00:03:30.940 | on proving out a single cure. And if it works, the return on investment is so high that it doesn't
00:03:36.140 | really matter. To take a different example, tab completion like those that you see in popular
00:03:42.380 | IDEs, like cursor, all are very, very dependent upon snappiness. The user expects that when they
00:03:48.540 | press tab, they will see a recommendation for the next line or the next set of, you know, tokens very,
00:03:54.780 | very quickly. And then to take another code example, with respect to async code commits, things like,
00:04:01.100 | you know, cursors, what's it called? It's agent mode. And, you know, other applications where the chatbot or
00:04:11.900 | applications working next to the user, there's not as much a consideration for latency, but there is
00:04:17.100 | a concern for both quality and cost. And this sort of breaks down, or this sort of depends upon what
00:04:25.020 | the user expects from the application. Does it, do they expect it to be fast? Do they expect it to be
00:04:30.780 | slow? Are they involved in the loop with this application? Now, there are a series of, you know,
00:04:37.180 | techniques that are pretty commonly known about that all, you know, support the manipulation of this
00:04:41.980 | frontier. For example, quantization speeds up your latency and it also decreases your cost because you
00:04:47.100 | can produce higher batch sizes. Retrieval augmented generation generally slows down your application,
00:04:52.300 | makes it higher latency, increases the cost, but also increases the quality. And reasoning, for example,
00:04:58.220 | similar, you know, you produce more tokens to think. And changing the model config allows you to do any of
00:05:03.340 | these things. If you change how the model is represented in a parallel manner, you can significantly
00:05:08.700 | change the characteristics of speed, cost, and theoretically quality if you're talking about
00:05:13.980 | non-haloed context parallelism. The thing that I want to impart upon you before we jump into, like,
00:05:19.740 | a lot more of these advanced techniques is that these techniques can be compounded. So, for example,
00:05:23.980 | if you have an initial application and has some required performance, you can actually stack,
00:05:28.860 | for example, retrieval augmented generation in order to increase the quality, but make the latency worse.
00:05:34.140 | And you can also stack on top of that quantization of the model in order to speed up your latency.
00:05:40.620 | The point I'm, you know, trying to make here is that you really have this toolbox of sets of large sets
00:05:47.500 | of tools that you can use together. And the tools themselves are not independent and can be combined
00:05:53.020 | in very sometimes non-obvious ways in order to actually break your Pareto frontier or squeeze it
00:05:59.740 | in different directions in order to support your application. So, there are three things outside of
00:06:05.820 | those techniques that I tend to think drive, you know, how you can modify the Pareto frontier going forward.
00:06:16.300 | Those three are scale, structure, and dynamism. So, one of the things that is, you know,
00:06:22.860 | really relevant in the realm of scale is disaggregation. So, for those that aren't aware,
00:06:29.420 | KV caching is a technique by which you take the key and value vectors that are associated with each token
00:06:37.100 | and you cache them so that when you're doing autoregressive generation, you don't have to generate
00:06:41.740 | the entire set of key and value vectors for the entire sequence up to this point. You can just
00:06:46.140 | generate new ones and put them back into the KV cache. What this actually means is that we effectively
00:06:52.460 | have two phases of generation. One in which you're generating the pre-fill or filling up your KV cache
00:06:59.500 | and one in which you're actually generating new KV cache as well as new tokens and producing output.
00:07:05.500 | Now, disaggregation as a technique basically allows you to have these, you know, two phases which were
00:07:12.940 | typically used on the same set of GPUs onto multiple different workers and sets of GPUs.
00:07:19.500 | And this provides a couple of key benefits that we'll go into right now. The three really big
00:07:25.260 | benefits here are that you can really now take two sort of phases that have very different needs.
00:07:32.380 | Pre-fill is very compute bound and decode depending on that application and model can be very memory bound.
00:07:38.620 | And it allows you to do a granular load matching between those two phases. And what this means is,
00:07:43.420 | you know, compute saturates relatively early to use DeepSea as an example. Compute saturates
00:07:49.420 | relatively early and you may use relatively few GPUs for your pre-fill instances and have them handle a
00:07:55.980 | lower batch size. But handle a much larger batch size with many more GPUs for your decode instances.
00:08:02.700 | And this split and this heterogeneity between the two actually allows you to produce far more performance.
00:08:09.500 | The other thing is that, you know, one of the problems is that if you have in-flight batching,
00:08:16.620 | you have many tokens coming in at the same time that are in different phases of generation, right,
00:08:20.860 | if you have a request that's doing pre-fill and a request that's doing decode on the same machine,
00:08:24.300 | you get scheduling conflicts and the scheduler basically has to decide whether or not it handles
00:08:28.380 | new tokens. There's some techniques to handle this, like in-flight batching and chunk piggybacking,
00:08:33.820 | or sorry, chunk piggybacking. But generally, there is a cost to doing that mutual scheduling.
00:08:39.340 | So splitting this out makes the scheduling simpler. Now, there's an asterisk to this, which is that,
00:08:44.060 | sorry, really quickly, and I'll go over the performance numbers. I'm going to use Llama70B as an
00:08:48.620 | example. Right here, we have on our left axis, or our Y axis, we have the tokens per second per GPU.
00:08:54.540 | On our X axis, we have the tokens per second per user, right? Up and to the right is better.
00:08:59.020 | If we choose one operating point at latency, disaggregating on the same number of GPUs, 16 total H100s,
00:09:05.820 | we can achieve up to two times the tokens per second per GPU at a fixed latency, which means that
00:09:12.300 | you're now paying two times less for your application. There are some constraints, though.
00:09:18.460 | The use case really does dictate performance for disaggregation. For example, low input length
00:09:25.500 | use cases have little to no speed up, because you don't actually have as much of the scheduling
00:09:31.180 | problem. They're very pre-filled light, so you're basically just doing decode the entire time.
00:09:34.300 | And then, per the graph, disaggregation, and I'll go back to the graph, actually, disaggregation is useful
00:09:41.820 | usually in the middle of the graph. In very high latency, high throughput scenarios, which would be the left and
00:09:47.900 | top of the graph. And low latency, low throughput scenarios, the bottom right,
00:09:52.220 | aggregated tends to reconverge with disaggregated and produce a little bit more performance in those
00:09:58.620 | cases. That being said, for a lot of user, you know, interactive applications, disaggregation makes
00:10:05.980 | the most sense because users tend to read that between or care about things in the realm of 20 to
00:10:13.100 | 200 tokens per second. The other thing that's kind of a caveat about this is that configuration is
00:10:20.140 | really important. Since you're separating these two phases into pre-fill and generation, the balance
00:10:25.820 | between the number of workers for pre-fill and decoding dictates the performance. So, for example,
00:10:30.860 | if you have too many decode workers, you're basically gonna have decode workers that are starving for
00:10:36.460 | work. And if you pre-fill workers, they're going to be generating work for the decode workers, and the
00:10:41.500 | decode workers are gonna be being pushed down by, you know, just an increasing amount of load and
00:10:46.540 | increasing queue depth. And the other thing is that modifying this is kind of expensive and hard,
00:10:53.580 | because the balance between pre-fill and decode depends on the parallel configs of each. So,
00:10:58.060 | it's like this really wide configuration space. One other thing that we talk about with respect to
00:11:03.580 | scale is routing. So, we talked about how this KV is important. One of the things that we have to do for
00:11:09.900 | pre-fill decode disaggregation is that we need to actually transfer the KV between machines. And
00:11:16.060 | in some sense, there's actually an affinity for some machines to do some work, since the KV cache of
00:11:21.820 | previous request is actually stored on those GPUs or offloaded onto system memory, host, or external
00:11:29.580 | storage during the course of inference. So, I actually labeled this wrong. This is not the smart router.
00:11:37.260 | This -- in a naive case, you would route pretty much exclusively randomly, right? Or towards, you know,
00:11:48.860 | anything. So, in this case, we're biasing towards -- we're not biasing towards anything. We're sampling
00:11:54.300 | randomly. Alternatively, you know, if we're talking about this -- if routing to worker three in this
00:11:58.620 | case, it could also be that you're optimizing for purely your KV match. If you're doing -- this is
00:12:05.420 | actually inverted -- if you're doing a KV-based router, you may end up biasing towards machines that
00:12:13.580 | have too high KV load and, therefore, are not going to be able to handle the request and you end up with
00:12:16.780 | queueing. In a smart case, you actually want to minimize the -- sort of this cost function that
00:12:23.260 | includes both the amount of prefix match that you can get from -- or maximize the prefix match that you
00:12:29.580 | can get from the work that's already been done on that node and the amount of load that already exists
00:12:35.660 | on that node. And as you scale out, as you get more and more GPUs in a deployment, you actually end up
00:12:44.300 | with more and more represented KV space that's local to those machines. And because of that, having a
00:12:50.540 | larger and larger deployment means that you get an asymptotically increasing KV cache hit rate, which
00:12:56.220 | means that you're doing less and less pre-fill work over time. So routing, you know, here to give it a report
00:13:03.660 | card, increases your speed and cost, and doesn't really have an effect upon quality because it's -- it's doing
00:13:08.460 | the same work that it would normally do. Now, we talk about structure. Structure is really important
00:13:14.380 | because we have a lot of these workloads that you guys have probably seen at the AI Engineers World Fair, like
00:13:19.180 | agents, for example. Agents impart a structure on the workload in that they have moderately predictable
00:13:26.060 | usage patterns between concurrent requests. So an example here is inference time scaling. This is a
00:13:30.940 | cool graph I'll go over really quickly. For example, we have three models here. In green, we have an 8b
00:13:35.820 | model. In yellow, we have a 49b model. And in red, we have a 235b model. We find that with inference time
00:13:42.380 | scaling -- that is to re-query the model and to, you know, prompt it to reconsider its results or reason more
00:13:47.740 | about its results, we can produce better and better results. And you actually see this really interesting
00:13:52.140 | trend where with about three or four times of re-querying, we can see that the 8b model is basically
00:14:00.140 | on par with respect to quality as the 49b model. And the 49b is almost on par with respect to quality
00:14:06.860 | as the 235b model. And we note here that, like, the cost of querying that 8b model,
00:14:16.620 | you know, even querying it multiple times is actually lower than querying the larger model,
00:14:24.460 | right? And in this sense, you know, we basically see that inference time scaling can be considered
00:14:31.180 | sort of as, you know, increasing quality at the cost of speed and at the cost of cost, right? Because
00:14:37.820 | you're re-querying it. But alternatively, if you keep quality fixed, you can basically get lower
00:14:46.700 | latency and lower cost by using a smaller model and re-querying it multiple times. And the structure
00:14:53.340 | that we infer from doing that re-querying allows us to do better scheduling. So in this graph, we have a
00:14:59.660 | series of curves that represent basically the runtime of a given reasoning example from the natural plan
00:15:06.540 | dataset. And the -- basically the concurrency. So this is, like, a graph of, like, how many you can -- how
00:15:14.140 | many concurrent instances you can run at once. And we sample across all this concurrency. We see that
00:15:20.780 | implanting disaggregation gives us a small benefit, mostly because this dataset is very ISL -- short ISL,
00:15:26.940 | long OSL. You don't get a whole ton of benefit from disaggregation. In this case,
00:15:30.860 | basically making -- you know, removing a round trip by making the re-queries come from the router
00:15:38.060 | instead of coming from the user or the client on the outside, allows you to really decrease these
00:15:43.340 | round trips with respect to latency. And then on top of that, making the router aware and making the LLM
00:15:48.300 | scheduler aware that you are doing, you know, repeat work, you're re-querying it, actually gives you an
00:15:54.860 | increased benefit that is the red line to the green line. That is to say, amongst a wide variety of
00:16:00.700 | models, if we assume that the quality is fixed, we can actually use inference time scaling and some smart
00:16:06.780 | techniques in order to significantly decrease latency and increase throughput while maintaining the same
00:16:11.260 | quality. One last thing, and I'm going to go through this really quick because I'm getting low on time,
00:16:16.860 | is manipulating K and V values, right? We've sort of talked about how before there's this work that
00:16:22.620 | we do in pre-fill that we don't want to lose. We do routing to ensure that we don't lose this KV.
00:16:29.500 | And, you know, if we have, like, a workflow where we know the run times of things -- so, for example,
00:16:35.900 | if we do a, you know, a tool call, for example, and we know this tool call takes a moderately
00:16:43.980 | deterministic amount of time, we basically end up with this KV eviction, right? If we have a tool call
00:16:48.860 | that takes 30 seconds, the KV is going to be swept out from HBM and you're not going to be able to use
00:16:53.500 | it in the future because it's no longer being cached. But if we know that it's going to be used again,
00:16:59.260 | why not just offload it, right? Basically, inference time scaling gives you structure to manipulate your
00:17:05.900 | KV. Tool calling gives you structure to manipulate your KV. So, instead of doing another pre-fill
00:17:10.860 | the second time, you might, for example, do pre-fill once, do, you know, the LM call, the decode once,
00:17:18.940 | move it to host memory, and then, you know, at the time at which you expect the tool to complete,
00:17:24.140 | you move it right back into GPU memory so it's ready for the next LM call that will include this
00:17:28.860 | added context from the tool. So, KV manipulation, you know, again, increases your speed and decreases
00:17:35.580 | your cost while also, you know, improving your quality. Or not improving quality, keeping quality
00:17:40.700 | constant. The last thing that we have to talk about here is dynamism. Worker specialization is really
00:17:46.380 | important. As I said, since you have different characteristics of disaggregation at different
00:17:52.300 | input sequence lengths and output sequence lengths, you actually want to have a mix of aggregated and
00:17:56.940 | disaggregated workers based on where you are in the OSL/ISL histogram. So, at, you know, lower input
00:18:03.740 | sequence lengths and higher output sequence lengths, you might want to do aggregated with a higher tensor
00:18:07.260 | parallelism. In the middle of the range, you may want to use... In the middle of the input sequence
00:18:11.180 | range, you may want to use disaggregated. And in the, you know, long context, you know, regime,
00:18:18.860 | you may want to use disaggregated with context parallelism. Now, again, this differs model to
00:18:23.980 | model. And this is just an exemplary graph. But generally, if you specialize workers, you can also
00:18:31.180 | increase... Increase your speed, decrease your cost while keeping quality the same. Because, again,
00:18:35.660 | you're not actually touching the execution... What the model is executing. You're not touching the math it's
00:18:40.220 | doing. One last thing about dynamism is load balance is quite important. As I mentioned earlier, doing...
00:18:48.220 | Looking at the amount of P and D workers is really important to determine whether or not your disaggregated
00:18:54.620 | deployment is going to be successful. So, for example, if you have a histogram that you initially create
00:18:58.780 | your configuration based off of, for example, if you have app A and app B that have, like,
00:19:03.100 | these two input sequence length and output sequence lengths, you may end up with a scenario where a
00:19:08.540 | change in user distribution causes significant issues with your deployment. Your dec... In this case,
00:19:14.780 | by... When you increase your input sequence length and output sequence length by a little bit more,
00:19:19.900 | your input sequence length, you might create more demand for prefill workers than you do for decode
00:19:24.780 | workers. So, your balance will change over time. And this has been empirically proven by a wide variety
00:19:30.540 | of people that publish data. And you actually have to do auto-scaling across these two types of instances
00:19:39.500 | in real time to account for changes in user usage distribution of your platform. So, in this case,
00:19:46.140 | dynamic load balancing increases your speed and keeps your costs low. But mostly, it's really just
00:19:53.100 | essential to ensuring that disaggregation actually works to maximum potential.
00:19:58.940 | Okay. Last things. Here is the Dynamo repo. It's right here. It's github.com/ai-dynamo.
00:20:07.180 | We also have a Dynamo meetup that is being hosted tomorrow, Thursday from 5:00 to 8:00 PM here in San
00:20:12.540 | Francisco. Please come. We're going to be talking a lot more about how we actually implement these things at
00:20:17.420 | the event.
