back to indexAI Observability with OpenAI Agents SDK

Chapters
0:0 Agents SDK Tracing
0:17 OpenAI Traces Dashboard
2:3 Agents SDK Tracing Setup
3:0 Access to OpenAI Traces
4:3 Creating Agents SDK Traces
5:29 Custom Traces
8:24 Tracing Agent Tools
12:15 Conclusion
00:00:00.000 |
Okay so we're going to move on to chapter two of the Agents SDK course. In this chapter we're going 00:00:05.940 |
to be taking a look at the built-in tracing that comes with the SDK. So just to give you a quick 00:00:13.160 |
preview of what tracing looks like when you're using it, it looks like this. So this is all 00:00:19.520 |
built-in. I haven't, or at least for most of these, I have not done anything much beyond passing in an 00:00:26.560 |
API key. So this is one thing that Agents SDK does very well in my opinion. Just by passing my 00:00:33.480 |
OpenAI API key and turning tracing on in my dashboard, and I'll show you how to do that in a 00:00:39.420 |
moment, we get all of this information about what is going on within our Agents when we're using 00:00:46.940 |
Agents SDK. So this is an example from a future chapter that we are going to be working on, which 00:00:54.660 |
is where we're going to be building this essentially GFK RAG pipeline. And in this example we have this 00:01:01.580 |
GFK document assistant. You can see that this is a chat response. So this is when we're getting the 00:01:08.960 |
LLM to generate some text. In this case I can see that the LLM generated some text. It decided to use 00:01:14.040 |
the GFK file search tool. Here I must have been searching something to do with some guy here, 00:01:21.720 |
Valerie. And we can see what was returned. Okay. And we also get to see how long each one of these steps 00:01:28.960 |
took. So that initial tool call from the LLM is about a second. The response time there, super fast, 00:01:35.960 |
it's about, well, 100 milliseconds there. Then the final response, the final response has a bit more 00:01:42.600 |
to process because we've just given it a ton of documents to read and it needs to respond. You can 00:01:48.640 |
see that it went through and got all this input here and then the output was this. So that's pretty cool. 00:01:57.740 |
We have all that and you'll see it's super easy to sell. This is a pretty short chapter. 00:02:02.700 |
So switching across to our code and make sure I'm using the agents SDK course environment there. 00:02:09.040 |
If you are in Colab, I will just pre-warn you that tracing doesn't work, at least not by default, 00:02:16.980 |
in Colab as of today. Maybe in the future it will, but if you do want to run this, you will 00:02:24.100 |
unfortunately just have to run this locally. You can't do this part in Colab. At least not right 00:02:29.520 |
now. In the future, maybe you can. So we come down. If you are running this anywhere remotely, 00:02:37.100 |
of course, you will need OpenAI agents. So that is to install. And the first thing I'm going to do is 00:02:43.140 |
just see how we set this up so that we can go into the OpenAI dashboard and see all these traces because 00:02:51.900 |
by default, if you're part of an organization, you can't. This information is by default only 00:02:58.480 |
accessible by the organization owner. So if you're an engineer in a larger company, you will need to 00:03:04.100 |
go through a few steps, which I have outlined here. So we first need to click that little settings icon 00:03:10.400 |
at the top. We're then going to click on data controls. We should find a little section here, 00:03:16.420 |
which allows us to set the log visibility, right? And this includes traces. So you're looking at your 00:03:23.720 |
response logs, stored, check completions, and traces. That will need to be set to be visible either to 00:03:31.020 |
everyone or visible for selected projects or just visible so that you as a engineer can see it. 00:03:37.800 |
So once you have selected the required permissions there, you click save. Now, once you've gained access, 00:03:44.380 |
you should actually be able to see traces already. And you can do so by going to your dashboard, go to traces, 00:03:50.620 |
and then you see here we have all of these traces. So you should be able to see this page. If you can't, 00:03:57.560 |
you need to talk to whoever owns your OpenAI organization and fix that. Once you've confirmed, 00:04:04.180 |
you can see everything. Let's switch back to the notebook, and we're going to start creating some traces. 00:04:08.420 |
So we will need an OpenAI API key, of course. So you just enter that here. Then we're going to go ahead 00:04:15.060 |
and create a basic agent. Now, as usual, agent object will have that name instructions and model. 00:04:22.500 |
You will see these in the tracing dashboard. Okay, so we're going to start with tracing prompt agent, 00:04:29.620 |
speak like a pirate and the model there will be GT 4.1 nano. So we initialize that, come down to here, 00:04:37.460 |
and we're going to say, write a one sentence poem. We run that. And what we should see, if we navigate 00:04:45.860 |
back to our browser, click on the most recent trace, and we just see, okay, we've got that tracing prompt 00:04:53.780 |
agent. So that's the agent name that we just created. And we can see what happened inside there. 00:04:59.460 |
So it used 43 tokens. It used the 4.1 nano, and this is the April 14th model. The instructions 00:05:06.820 |
were speak like a pirate. Input from us, the user was write one sentence poem. And we can see the 00:05:13.540 |
assistant output there. So that is pretty self-explanatory. There's nothing, we literally did 00:05:20.340 |
nothing. We just entered our API key and it worked. So that's great, but there is a little more to this. 00:05:27.460 |
So I want to go through and we'll just see what else we can gather from traces or how we can even set 00:05:34.660 |
our own custom traces. So starting with the custom traces, to customize our tracing, we use the trace 00:05:43.620 |
function from the agent's SDK library. And with this, we can add or modify any of the parameters that we 00:05:52.740 |
are tracking. And that will look a little like this. So we'll have this with trace and then we would have 00:05:58.260 |
any of our code that we want to trace here. And that doesn't necessarily actually even need to be 00:06:03.940 |
agent's SDK code, right? If you have a particular tool and there's something you want to track with 00:06:10.420 |
that tool, you can, you can do that using this. Although that isn't necessarily the intended use 00:06:15.940 |
of the traces here. So let's come down a little bit and we're going to import that trace object. 00:06:24.100 |
And I'm doing with trace, I'm setting the workflow name. So I can, I can do this. I can set a default name. 00:06:29.700 |
I'm going to call this the prompt agent workflow. You can see that I'm setting a group ID here. So if 00:06:34.980 |
we want to group things together, we can do, I'm going to call this one agents SDK course tracing. So 00:06:39.940 |
all of our, the traces we create in this little chapter, we can put under this group ID. And what 00:06:46.180 |
I'm going to do is run this. Okay. So I'm just running the same thing again, just within the trace. 00:06:53.220 |
Let's run that. Switch over to our browser and we should see an update here. You can see the workflow, 00:07:01.700 |
the name is changed, prompt agent workflow. Now by default, if you don't set the workflow name, 00:07:07.620 |
it will just be agent workflow. If you do set the workflow name, this is what will appear, right? 00:07:13.540 |
Your custom workflow name. Now for all that other information, well, the group ID actually that we 00:07:19.620 |
added, we'd have to click in to here. We come across to details, I believe, and we can find a group ID 00:07:27.540 |
there. Okay. So that's that agents SDK course tracing. Now, if you come up here, you can also 00:07:40.420 |
And now we can see, you know, I've done this a couple of times. So you can see all the, 00:07:48.020 |
all of the cases where I have set my course or group ID, sorry, to be agents SDK course tracing. 00:07:55.220 |
So I could go into here, go into details, and you can see that there as well. As well as that, 00:08:00.580 |
you can, as you can probably see here, search by the workflow name. So I've got web search agent. Let's 00:08:09.140 |
Our filter for that, let's remove this filter and see how many of those we have probably. Oh, just three. Okay. 00:08:16.500 |
So we have three workflows where I set to web search agent. So you can, you can filter by that as well. 00:08:23.780 |
Now let's come down and let's have a look at how we would trace tools. So we are going to be using the 00:08:31.780 |
web search tool from open AI. We're going to be providing this as a tool, obviously to a agent. 00:08:38.500 |
The agent's name will be tracing tool agent. Yeah. You can see that the instructions here are your 00:08:45.460 |
web search agent searches the web information on the user's queries. Okay. And we're using 4.1 mini here. 00:08:52.420 |
Nano isn't supported for tool use or it's not recommended for tool use. So it's best to use mini there. 00:08:59.460 |
Run that. And I'm going to say, what are the current world headlines? And this will usually come up with 00:09:04.100 |
something. Yeah. Yeah. Well, fun in, in, in some way. One thing that I will just know here is 00:09:13.540 |
look how long that took. Yes. It's very long web search with the built-in opening our web search tool. 00:09:20.740 |
I just wouldn't generally recommend it too much. It's slow, slow, and not that good. So it's fine. 00:09:28.740 |
You can use it, but I would use other tools if you can. So let's see what that looks like in our traces. 00:09:36.660 |
Okay. So we have this agent workflow. That's the default name. So that must be it. Let's have a look. 00:09:40.980 |
Okay. Let's take a look in here. So we see, okay. It, there was the web search tool was used. 00:09:49.300 |
We can see, okay, user, what the current world headlines search the web. It has, okay. Middle East. 00:09:56.340 |
Ukraine. Ukraine. It opened a page for me. Okay. Back to this. International relations, 00:10:06.260 |
natural disasters, science and technology list. That one's nice. Very cool. So, yep. I mean, you know, 00:10:16.740 |
world news. Lovely. That was actually better than a lot of the world. That's actually not bad for the 00:10:22.740 |
OpenAI web search. A lot of time, I get a lot of rubbish from it. So it could be worse. 00:10:30.740 |
So yeah, we can see what happened there. Oh, and this is just the output, right? So this is like a really 00:10:38.180 |
big response that we got from our agent with a ton of sources, ton of information. So really not too bad, 00:10:45.940 |
actually. Even for that 13 seconds, I suppose. It could be, it could be worse. It could also be better. 00:10:51.140 |
Okay. So we can come down now. What, you know, what we just saw is that we had the, it was just called 00:11:00.500 |
the tracing tool agent. Maybe what we'd like to do is actually give that a more, the workflow a more 00:11:05.700 |
specific name. So in this case, we're going to call it that web search agent. It's what we saw before. 00:11:12.980 |
I'm also going to add metadata. Okay. So we can add metadata in here to, well, we can, we can search 00:11:21.860 |
or filter based on that metadata. I'll show you that in a moment. So let's run this and jump across 00:11:28.820 |
to our browser. So we can see, we have the website agent workflow in here. Okay. It's, I think it's still 00:11:36.580 |
running if I'm no, no, no, it has. Oh, that was, it was quite fast that time. So 6.6 seconds. And yeah, 00:11:45.140 |
we got, we'll get more news there. The, we can look in the details. We have group ID. We can see metadata 00:11:51.700 |
here and we can filter by that metadata. So if I go into here and I write tools, web search tool, 00:12:04.900 |
and we can see all of the cases where that metadata has been added. So you can, you'd add a lot of 00:12:09.940 |
various metadata in that, whatever you need basically, which is, is really helpful. Great. So that is our 00:12:17.780 |
quick introduction to the agent's SDK tracing. As I think you've seen, it's pretty useful and it requires 00:12:26.980 |
minimal setup on our side. We, you know, we kind of went in there, we're using the, the trace context, 00:12:34.020 |
but you don't even need to do that. It's I, I honestly, I pro in most projects, I probably wouldn't 00:12:41.780 |
do that. I would just set my API key, allow the traces to be collected and go and review them when I need to 00:12:48.180 |
review them, which I think is just really helpful. Now, that is it for this chapter. It's a quick one.
